HVAC/R Training Units and Curriculum

Midlands Technical College Training Showcase

Watch as Joey Henderson, Program Director for HVAC at Midlands Technical College, talks about the excitement in HVAC training, and his relationship with North Park Innovations.  Hear from students as they describe what learning at Midlands Tech has done to prepare them for a future career in HVAC/R.

Midlands Technical College

Download our Catalog

The training units represent a wide variety of subjects in the heating, refrigeration, air conditioning and electrical industries. The training units range from demonstrating simple concepts to illustrating advanced troubleshooting and servicing techniques.

Download our Catalog
iConnect Training Catalog 2019

HVAC Curriculum to Help Your Students & New Techs or Apprentices get Better, Faster!

Basic Refrigeration Fundamentals

Introducing the first curriculum package powered by the iManifold platform. Students will utilize today’s cutting edge technology to understand the key principles of refrigeration, while learning to practice safe work habits.

Email Caroline or call 716-468-4047 to learn about this affordable per-seat offering that is designed to teach with our TU-805 Mobile Table-Top Refrigeration training unit.

TU-100 Refrigeration Trainer Showcase

The TU-100 Basic Refrigeration Trainer unit demonstrates domestic refrigerator and freezers, self-contained air conditioning units and reverse cycle or heat pump systems. Listen to Jason Obrzut as he walks you through the operation of this training unit.

See our Training Units
TU-100 Basic Refrigeration Trainer

iConnect Training provides educational equipment, supplemental tools, and materials to vocational trade schools and institutions around the world.

About Us
TU-106
Read more

TU-106 Dual-Application Commercial Refrigeration Trainer

This deluxe trainer can show operation of multi-evaporator systems, dual temperature applications (low and medium) and an electric resistant heat defrost cycle.

Specifications

Compressor: Single phase, 1/2 HP semi-hermetic (bolted reciprocating-type) 120VAC, 60 Hz, 15 Amp
Condenser and Low and Medium Temperature Evaporators: Copper tube coils with aluminum fins and adjustable speed fans mounted on back of panel
Uses HFC 134a refrigerant
Mounting stand: 72″ L x 20.75″ W x 72″ H
Panels: 1⁄4″ thick HDPE with steel reinforced component shelf
Electrical requirements: 120VAC, 60 Hz

This training unit includes a standard-range iManifold® 900C System Analyzer kit for real-time system performance analysis suitable for projector or large screen display in the class-room. This kit works with most smart devices (customer to provide, with appropriate cable.) It also comes with a complementary 801PL Pulse Kit, 1-year iManifold® Pro+ subscription is included for one user; additional student subscriptions are available.

TU-810
Read more

TU-810 EEV Table-Top Air Conditioning & Refrigeration Trainer

This training unit demonstrates basic refrigeration and air conditioning principles in a compact size perfect for in the classroom or mobile training.

Specifications

Electrical Requirements: 120VAC; 60Hz; 15A
Overall Size: 34″ L x 16″ W x 16″ H
Weight: 80 lbs.
Uses HFC 134a Refrigerant
1⁄3 HP hermetically sealed reciprocating compressor.

This training unit includes a standard-range iManifold® 900C System Analyzer kit for real-time system performance analysis suitable for projector or large screen display in the class-room. This kit works with most smart devices (customer to provide, with appropriate cable.) It also comes with a complementary 801PL Pulse Kit, 1-year iManifold® Pro+ subscription is included for one user; additional student subscriptions are available.

925c
Read more

TU-805 Mobile Table-Top Air Conditioning & Refrigeration Trainer

This training unit demonstrates basic refrigeration and air conditioning principles in a compact size, perfect for in the classroom or mobile training.

Specifications

Electrical Requirements: 120VAC; 60Hz; 15A
Overall Size: 36″ L x 16″ W x 16″ H
Weight: 80 lbs.
Uses HFC 134a Refrigerant
HP hermetically sealed reciprocating compressor.

This training unit includes a standard-range iManifold® 900C System Analyzer kit for real-time system performance analysis suitable for projector or large screen display in the class-room. This kit works with most smart devices (customer to provide, with appropriate cable.) It also comes with a complementary 801PL Pulse Kit, 1-year iManifold® Pro+ subscription is included for one user; additional student subscriptions are available.

TU-208 forced-air and hydronic heating925c
Read more

TU-208 Combination Forced Air & Hydronic Heating Trainer

The forced air and hydronic heating trainer provides demonstration and service practice with forced air and hydronic heating systems, including hot water heating systems. All components are full size, completely operational and are standard brands of equipment.

  • Gas fired forced air furnace
  • Oil fired hydronic boiler
  • Air conditioner
  • Fuel tank sold separately
  • iManifold Kit for full diagnostic testing and troubleshooting of system components.

All-Electric model also available (model TU-208E)

This training unit includes a standard-range iManifold® 900C System Analyzer kit for real-time system performance analysis suitable for projector or large screen display in the class-room. This kit works with most smart devices (customer to provide, with appropriate cable.) It also comes with a complementary 801PL Pulse Kit, 1-year iManifold® Pro+ subscription is included for one user; additional student subscriptions are available.

TU-100 Basic Refrigeration Trainer925c
Read more

TU-100 Basic Refrigeration Trainer

This training unit demonstrates domestic refrigerator and freezers, self-contained air conditioning units and reverse cycle or heat pump systems.

Specifications

1/3 HP hermetically sealed reciprocating compressor Trainer operates on HFC 134A refrigerant
Panels are 1⁄4″ thick HDPE with steel reinforced component shelf
Uses HFC 134A refrigerant
Electrical requirements: 120VAC; 50/60 Hz; 10A
Overall size: 36”W x 18”D x 73”H

This training unit includes a standard-range iManifold® 900C System Analyzer kit for real-time system performance analysis suitable for projector or large screen display in the class-room. This kit works with most smart devices (customer to provide, with appropriate cable.) It also comes with a complementary 801PL Pulse Kit, 1-year iManifold® Pro+ subscription is included for one user; additional student subscriptions are available.

Watch Videos

Connect Any iConnect Training Unit to the 925CX iManifold

See the New Portable Training Unit in Action with Students.

TU-810 Training Unit Showcase

Watch 12 Training Units get built in 2 minutes!

Emilio Gelfenstein
Campus Director & Chair of HVAC Program, Florida Career College

“I like the fact that we have an unobstructed view of the workings of the air handler, and we can show students the parts without having to take covers off. Now that they are on a smaller platform, it’s easier to move from classroom to classroom. These Training Units are well put together, and everything is sturdy. They give us the ability to mimic service problems and have students try to overcome them with good methodology.”
